No strikes ever Lightning elimination solutions for the oil & gas industry
percunos.com
Lightning Protection that works. Period. How can we claim this? Because in over a decade since launch and 8000+ installations worldwide, there has never been a recorded strike on property protected by this CMCE device.
Percunos, LLC
Proof it works Lightning strike maps “before” and “after” installation of the CMCE devices show a clear reduction of atmospheric electrical activity (area maps from the vicinity of the AES-Colon Facility Panama, a representative large-scale installation described on the following pages.)
Simple and 100% effective: Installed on your site, the CMCE Lightning Suppressor eliminates factors that cause lightning before it strikes.
Lightning strike activity before CMCE device installation
Maps represent a compilation of data from 2 years before and 2 years after installation of CMCE devices
AES-Colon LNG Project
Strikes mitigated in the same area after CMCE device installation
AES-Colon LNG Project
Case Study
Percunos, LLC
AES Colon - Panama
Map of CMCE device coverage
Property: AES-Colon LNG Power Plant Facility including 180,000m 3 LNG storage tank, the first of its kind in Central America Problem: The plant was consistently knocked offline due to recurrent lightning strikes in an area of consistent storm activity. Since this facility supplies power to large parts of Panama, including the Panama Canal, it is crucial that operations run without interruption. Solution: Eliminate the threat of strikes (proven by map data on preceeding pages) by installation of 26 CMCE devices installed on chimneys, towers, electrical substations, tanks, docks, cranes, pipe racks and buildings. The plant was in the process of an update and so the decision was made to replace 120 Franklin rods with a grid of 26 total CMCE devices.
Advanced lightning
Case Study
elimination technology
Percunos, LLC
Watusi Energy - West TX A tank battery owned by Watusi in Midland, Texas, suffered a lightning strike in 2020, which resulted in a devastating and complete loss of the facilities. Even though the site had a spline ball ionizer network installed, a lightning strike was not averted. After rebuild, Watusi Energy instead chose a CMCE device to protect the rebuild. Since installation, there have been zero recorded lightning strikes at this facility.
WATUSI SITE AFTER STRIKE
WATUSI SITE BEFORE STRIKE
Spline Ball network
WATUSI SITE TODAY AFTER REBUILD
Location of CMCE Device
Case Study Select Energy - Carthage, TX
Percunos, LLC
Installation Details One CMCE-55 Lightning Suppression Device was installed on an existing flag pole. A grounding system was installed at the pole base. One device covers this entire facility in a 180 ft radius of protection.
Property: Select Energy Longbranch Tank Battery Facility
Protection: CMCE-55 device pole-mounted
Device Specs: 6 inches wide x 8 inches high, 5.2 lbs, coverage radius of 55 meters/180 feet
Location of CMCE Device
CMCE Device Grounding
Case Study
Percunos, LLC
True Oil - North Dakota
Pole-mounted device installed on existing tower facilities
Property: Hagen & Redwing Creek Unit Tank Battery Facilities
Protection: CMCE-55 devices installed on existing tower facilities
Device Specs: 6 inches wide x 8 inches high, 5.2 lbs, coverage radius of 55 meters/180 feet
ZERO lightning strikes since 2020 with CMCE devices installed in strategic locations
Installation Details Two (2) CMCE-55 Lightning Suppression Devices installed on existing tower facilities. CMCE units were installed at the top of the tank batteries and connected into existing grounding loop with a braided grounding cable via mechanical connection.
Want to know more? Let's talk about solutions. Contact us at 832-838-4485 or 888-878-4589 or email info@percunos.com
Case Study
Percunos, LLC
Compass - North Dakota
Installation Details CMCE Lightning Suppression Devices installed on SWD facilities with existing spline ball ionizer lightning protection system, which have at times proved ineffective for lightning prevention.
Property: Saltwater Disposal Facilities at several sites
Protection: CMCE-55 & 120 devices installed on tower facilities
Device Specs: CMCE-55: 6 inches wide x 8 inches high, 5.2 lbs, coverage radius of 55 meters/180 feet CMCE-120: 9.5 inches wide x 14.5 inches high, 17.5 lbs, coverage radius of 120 meters/393.7 feet
ZERO lightning strikes since 2021 after CMCE devices installed at multiple sites
Want to know more? Let's talk about solutions. Contact us at 832-838-4485 or 888-878-4589 or email info@percunos.com
Advanced lightning
elimination technology
Percunos, LLC
Percunos, LLC
Additional Site Photos Compass - North Dakota
percunos.com
Contact us to discuss custom solutions to protect your people, property and venues. Percunos, LLC Integrated Lightning Solutions info@percunos.com
832-838-4485 888-878-4589
